Projection System

• DLP™

Light Source

• 210 W

Native Resolution

• 1280 x 800

Maximum Resolution

• 1920 x 1200

Brightness

• 4800 ANSI Lumens (Standard), (Compliant with ISO 21118 standard)

Aspect Ratio

• 16:10 (Native), 4:3 (Supported), 16:9 (Supported)

Contrast Ratio

• 20,000:1

Image Size

• 27″ (68.6 cm) ~ 7.62 m (300″)

Zoom Ratio

• 1.1x

Digital Zoom

• 2x

Lens

• f = 22 mm~24.10 mm, Manual Zoom, Manual Focus

Projection Offset (Half-Height)

• 100%

Projection Mode

• Front, Rear, Ceiling, Rear Ceiling

Display Color

• 1.07 Billion Colors (30-bit)
• 1.07 Billion Colors (30-bit)

Vertical Sync Rate

• 24 ~ 120 Hz

Horizontal Sync Rate

• 15 to 100 kHz

VGA In

• x1, D-sub

VGA Out

• x1, D-sub

Video

• x1, RCA

Audio In

• x1, 3.5mm mini jack

Audio Out

• x1, 3.5mm mini jack

S/PDIF

Speaker

• x1, 3 W Speaker
• x1, 3 W Speaker

RS232

• x1, D-sub

Security

• PIN Code Locking
• Kensington Lock
• Security Bar

Power Consumption

• 260Watts (Standard), 205Watts (ECO), 0.5Watts (Standby)

Installation

• Ceiling Mountable

[Dimensions (W x D x H)

• 11.80 mm (0.46″) x 8.70 mm (0.34″) x 4.10 mm (0.16″)
• 11.80 mm (0.46″) x 8.70 mm (0.34″) x 4.10 mm (0.16″)

Weight (Approximate)

• 2.4 kg (5.3 lb)
